功能點Feature and functions
●YQZPⅠ蒸汽燙平機采用蒸汽加熱,傳動采用調速調整,根據加熱溫度和織物厚度隨意調節速度。
●輥筒采用傳質不銹鋼制造,表面經磨削加工處理使織物磨損降到。
●運行可靠,采用減速器聯接皮帶輪及鏈輪傳動,并配置傳動引擎機構,運行平穩。
●副輥采用噴鋅處理,抗腐蝕能力強,經久耐用。
●YQZPⅠthe steam single roller irons out machine uses thetric heating, the transmission uses the velocity modulation adjustment, according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the mass transfer stainless steel manufacture, the surface causes fabric attrition after abrasive machining processing to reduce lowly.
●The movement is reliable, uses the reduction gear joint belt pulley and the sprocket feed, and disposes the transmission engine organization, the guarantee movement is steady.
●All vice rollers use spurt zinc processing, corrosion resistance ability, durable.
●YQZPⅠ蒸汽燙平機采用蒸汽加熱,傳動采用調速調整,根據加熱溫度和織物厚度隨意調節速度。
●輥筒采用傳質不銹鋼制造,表面經磨削加工處理使織物磨損降到。
●運行可靠,采用減速器聯接皮帶輪及鏈輪傳動,并配置傳動引擎機構,運行平穩。
●副輥采用噴鋅處理,抗腐蝕能力強,經久耐用。
●YQZPⅠthe steam single roller irons out machine uses thetric heating, the transmission uses the velocity modulation adjustment, according to heating temperature and fabric thickness at will adjustable speed.
●The big bowl uses the mass transfer stainless steel manufacture, the surface causes fabric attrition after abrasive machining processing to reduce lowly.
●The movement is reliable, uses the reduction gear joint belt pulley and the sprocket feed, and disposes the transmission engine organization, the guarantee movement is steady.
●All vice rollers use spurt zinc processing, corrosion resistance ability, durable.
技術參數Technical parameters
|
型號 model 項目 item |
YQZPⅠ2200 | YQZPⅠ2500 | YQZPⅠ2800 | YQZPⅠ3000 | YQZPⅠ3300 | |
| 熨平寬 | Biggest ironing width | 2200 | 2500 | 2800 | 3000 | 3300 |
| 熨平速度(m/min) | Ironing speed | 0-6 | 0-6 | 0-6 | 0-6 | 0-6 |
| 加熱溫度(℃) | Highest heating temperature | 158 | 158 | 158 | 158 | 158 |
| 蒸汽壓力(MPA) | Steam pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 |
| 蒸汽耗量(kg/h) | Steam consumption | 100 | 120 | 140 | 155 | 170 |
| 電機功率(KW) | Motor power | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| 額定電壓(V) | Rated voltage | 380 | 380 | 380 | 380 | 380 |
|
外形尺寸 |
Dimension (L×W×H) |
3400×1250×1250 | 3700×1250×1250 | 4000×1250×1250 | 4200×1250×1250 | 4400×1250×1250 |
| 整機重量 | Machine weight | 1300 | 1350 | 1450 | 1500 | 1600 |
